| Production Capacity | 1 inch X 1 inch – 50 ODF in hour |
| Size of Film drawn | 100 mm width X 200 mm Length |
| Coating Accuracy | Automatic Dragger, +/- 1 to 5 μm for a 100 μm dry coating over the entire coating width |
| MOC Non-Contact Parts | SS 304 |
| MOC Contact Parts | Aluminium |
| Product | Any Aqua base or solvent base formulation |
| Heater | Heater of 1 kW is provided in the insulating box to achieve the temperature from ambient to 100 C of glass table top |
| Control Panel | Advance control panel with digital temperature controller helps to control the temperature of table top with accuracy of +/- 1 degree Celsius |
| Electric Accessories | 230 V 1 Phase 50 Hz |
| Documents | User Manual, Warranty Certificate |
| Electric Consumption | 1 kw |
| Dimension (LXWXH) in mm | 700 (L) X 400 (W) X 300 (H) (Approx.) |
